automatic plastic cup screen printing machine DX-S101

automatic plastic cup screen printing machine

product:automatic plastic cup screen printing machine

model:DX-S101

printing color:1 color or multi color

Printing size:

Cylinder ¢20-100mm  Height 25-300mm

Oval   W25-120mm Height 25-300mm

Speed:cylinder 4,000pcs/hr

           oval 5,000pcs/hr

Voltage:AC380V 3Phase

Power:Machine(1.5KW)  UV(5KW)

Air supply:0.6Mpa

Gas:0.15Mpa

Machine size:L200*W100*H150cm

N.W:1000KGS

Printing consumables

• Screen printing plate
• Printing ink
• Squeegee (ink scrapper)
• Fixture

Machine features

• automatic loading system
• automatic flame treatment and UV curing system
• infinitely variable speed control system
• non-printing without bottles
• automatic pre contraposition system
• widly used for printing different shape domestic,medicine,food packing container printing,tools printing
• the machine adopt with PLC system and advanced touch screen for smart operation
• whole machine is combined with advanced motors and pneumatic parts to ensure infinitely variable speeds,automatic position matching,automatic feeding and non-printing without bottle
• can be used for printing oval,cylinder and irregular shape bottle.Such as plastic,glass,metal and so on.

Machine applications:

• Cosmetic bottles screen printing
• Medicine bottles screen printing
• Chemical bottles screen printing
• Sealant tube screen printing
• Jerry can screen printing
• Drinking bottle screen printing
• Filer screen printing
• Tea cup screen printing

Printing samples

•

•

•
